FEATURES:
· This machine is suitable for sample making for all kinds of rubber and plastic raw materials. The function is the name as the production granulator, just the capacity is decreased and power consumption reduced. When it is used for MIM/CIM granulation, it is especially for high hardness,high strength and very strong abrasion resistance granulating material.
· Single screw with two rolls to force feeding the mixed material, and decreased the step of crush in traditional granulating.
· It fits to develop new samples or new formula, save a lot cost.
· The working process is easy and safe, and easy to clean
SPECIFICATIONS:
Model | Screw Dia(mm) | Length Dia Ratio(L/D) | Main Motor Power(KW) | Twin Rolls Feeder (KW) | Capacity(KG/H) | Remark |
CF-30 | 30 | 12:1 | 3.75 | 0.375 | 5-10 | |
CF-45 | 45 | 12:1 | 5.5 | 0.75 | 25-35 | |
CF-70 | 70 | 12:1 | 11 | 2.2 | 50-80 |
